A packaging spec sheet is the document that turns your idea into something a factory can actually cut, fold, print, and glue — and most of the back-and-forth, missed deadlines, and wrong-color runs trace back to a spec sheet that left too much to guesswork.
This guide walks through what a usable spec sheet actually needs: the dieline, material callouts, color setup, tolerances, and file formats manufacturers expect, plus the mistakes that send proofs back for a second (or third) round.
Quick Answer
A packaging spec sheet your manufacturer can use needs a vector dieline with labeled cut, crease, and bleed lines; exact finished dimensions in consistent units; named material and board/caliper specs; colors called out as Pantone spot colors or CMYK (never RGB); print and finishing notes (coating, foil, embossing); and stated tolerances. Send it as a layered, editable file (AI or PDF), not a flattened image or a Word doc description.
What to Put on the Spec Sheet
Start with the dieline — the flat, unfolded outline of your box or package. It should show solid lines for cuts, dashed lines for creases/folds, and a separate line for perforations if any, each on its own layer or spot color so the factory’s software can read it automatically. Add a bleed area (artwork that runs past the cut line) wherever color or imagery touches an edge, since even small shifts in die-cutting will expose unprinted board otherwise. Folding cartons generally need a few millimeters of bleed; corrugated and rigid boxes usually need more because heavier board shifts further during cutting.
Next, lock down dimensions. List length, width, and depth/height for the finished package, plus any internal fit dimensions if the box holds a product or insert. State the unit (inches or millimeters) once at the top and stay consistent — mixing units inside one spec sheet is a common source of misreads. Include a tolerance (e.g., plus or minus a small percentage) so the factory knows how much variance is acceptable before a run gets rejected.
Then specify the material: board type (e.g., SBS paperboard, kraft, corrugated), flute type if corrugated (A, B, C, E, or F — each has a different thickness and crush resistance), and either caliper (board thickness) or basis weight (grams per square meter). Vague terms like ‘sturdy cardboard’ force the factory to guess, which usually means they guess wrong.
Color, Printing, and File Setup
Color is where the most expensive mistakes happen. Any brand color that has to match exactly across SKUs or reorders should be called out by its Pantone (PMS) number as a spot color, not built from a CMYK percentage mix — CMYK process colors can drift noticeably from press to press, while a spot color is mixed to a known standard. Never leave colors in RGB; it’s a screen format and has no reliable print equivalent. On the file itself, note which elements are spot color and which are process (CMYK) so the printer doesn’t convert something that was meant to stay exact.
List any finishing beyond flat ink: matte or gloss coating, spot UV, foil stamping, embossing/debossing, or soft-touch laminate, and where on the box each one applies — a small callout box on the dieline works well. Finally, send the file in a vector format (Adobe Illustrator .ai or a vector PDF) with fonts outlined or embedded, not a JPEG or PNG screenshot, since those can’t be scaled or edited without quality loss and don’t carry die-cutting line data.
Tips / Common Mistakes
The recurring issues: colors left in RGB instead of Pantone/CMYK, missing or too-thin bleed on edge-to-edge artwork, dimensions given in mixed units with no tolerance stated, material described loosely instead of by board type and caliper/GSM, and flattened image files sent instead of editable vector files. Also common — forgetting to version-date the spec sheet, so the factory and your team end up working from different revisions. Before sending a file into production, request a physical proof or a printed sample (a ‘dummy’ or comp copy) so you’re confirming color, fold, and fit on an actual piece of material, not just on screen.
If you’re working with an overseas or new manufacturer, add plain-language manufacturing notes next to anything that could be misread — glue tab placement, which panel is the front, and any panels that must stay unprinted for a barcode or compliance label.
Explore more: More packaging design guides.
packaging spec sheet FAQs
What file format should a packaging spec sheet be in?
A vector format — Adobe Illustrator (.ai) or a vector PDF — with the dieline, bleed, and artwork on separate labeled layers. Flattened images (JPEG, PNG) or text descriptions in a Word doc don’t carry the cut/crease data manufacturers need.
What’s the difference between a dieline and a spec sheet?
A dieline is just the flat outline showing cuts, creases, and folds. A spec sheet is the full package: the dieline plus dimensions, material, color, finishing, tolerances, and manufacturing notes the factory needs to actually produce it.
Do I really need a physical sample before full production?
Yes if the run is more than a small test batch. A printed proof or comp sample is the only reliable way to check color accuracy, fold strength, and fit — screen previews and digital proofs can look right and still be off once printed on real board.
